| Prod Model: |
WBPN2018AO |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Size: |
168mm*168mm |
| Min. Hole Size: |
0.4mm |
| Min Line Width And Distance: |
0.25/0.25mm |
| Solder Mask: |
Green |
| Silkscreen: |
White |
| Type: |
Rigid Circuit Board |
| Dielectric: |
FR-4 |
| Material: |
Fiberglass Epoxy |
| Flame Retardant Properties: |
V0 |
| Brand: |
Xzg |
Product Description
Specification:
Material:FR4 s1170
value:tg170
board thickness:1.6mm
copper thickness:1/1oz
Surface treatment:Enig
Application:consumer electronics
Our main process capability:
| Items | Standard | Advanced |
| Layer Count | 1-20 | 1-24 |
| Board Thickness | 0.2-5.0mm | 0.2-7.0mm |
| Max. Panel Size | 520X660mm | 680X1200mm |
| Min. Mechnical Drill | 0.2mm | 0.15mm |
| Min. Line width&space | 0.1/0.1mm | 0.076/0.076mm |
| Max. Copper Thickness | 6 oz | 8oz |
| Max. Aspect Ratio | 8:1 | 10:1 |
| Solder Mask Color | Green,Black,White,Blue,Red,Matt Green, Matt Black |
| Silkscreen Color | White,Black,Yellow,Grey,Orange |
| Base Material | CEM1,CEM3,FR4,IMS,aluminum |
| Surface Treatment | HASL(Lead Free),OSP,ENIG, ENEPIG,Immersion Silver,Immersion Tin, Hard Gold Plating,Tin Plating, Silver Plating |
Our Lead time:
| layers | 1~2layers | 4layers | 6layers | 8layers |
| sample | 3~4 days | 5 days | 6 days | 7 days |
| Volume production | 7~9 days | 11 days | 14 days | 15 days |
Why us:
UL (E246887), ISO9001/14001,ISO/TS16949certified.
1 Staff of 1000+
2 13+years experience,annual turnover USD 80Million+.
3 Full-process workshop,quality more guaranteed.(PCB all have double-checked before sending out).
4 as factory,price is more competitive.
5 Provide one-stop service:PCBA,SMT/DIP service.
Our Strength:
1 PTH PCB.
2 Aluminum PCB.
3 buried/blind via PCB.
4 high frequency PCB.
5 Heavy copper PCB-max 8oz
Xingzhiguang Technology, established in 2002, with factory area of 25, 000 sqm, total staff about 1200 and overall investment nearly USD 50 million, is a professional PCB manufacturer with factory located in Huizhou.
Through more than 10-year experience in PCB production, Xingzhiguang Technology is supporting an annual capacity of more than 900, 000 sqm, among which 30% is 1~2 layer and 70% is multi-layer, with the maximum layer count up to 20 layers; We can process many different kinds of laminates, such as FR4, high-Tg FR4, metal-based laminate (includes aluminum-based), Isola, Rogers and so on. In addition, we have started producing PCBA (PCB assembly) and FPCB (flexible PCB) as well since the end of 2014. We have passed a lot of authorized certification, including but not limited to UL(E246887), ISO9001: 2008, ISO/TS16949 and ISO 14001: 2004, and this ensures us to be capable to provide high-quality products to meet different customers' requirements.
Our products are widely used in fields of telecommunication, power supply, security surveillance, automotive, industry control, LED lighting & etc
Finally, as our commitment to the environment protection, we have also invested about USD 600, 000 in water-recycling system construction. This is the best witness to certify that xingzhiguang technology is a responsible enterprise.
