4CH Video/Audio H. 264 Compression Standalone DVR System (TW-4004AZ)
| Price: |
US $ 24.05-24.05/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
10/Piece |
| Pay Type: |
L/C,T/T,Paypal,Western Union |
| Prod Model: |
TW-4004AZ |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Dimension: |
(L×w×h): 245*215*42(Mm) |
| Weight: |
1.5kg |
| Type: |
Standalone |
| Video Compression: |
H.264 |
| Compressed Format: |
H.264 |
| Operating System: |
Windows |
| Application: |
Commercial DVR |
| Interface Type: |
BNC/VGA/HDIM |
| Video Input/Output: |
4 Channel |
| Audio Input/Output: |
4 Channel |
| Remote Control: |
With Remote Control |
Product Description
Support network live, backup, playback,P2P ,ICloud, serial number
Support remote view by mobile phone
4CH video input
| Technical Specifications |
| Product No. | TW-1004AZ |
| Video / Audio input |
| Video input | BNC 4CH In |
| Audio input | RCA 4CH In |
| Video/Audio output |
| HDMI output | HDMI 1CH Out |
| VGA output | VGA 1CH Out |
| Audio Output | RCA 1CH Out |
| Compression |
| Compression Method | H.264 |
| Real time recording support | CIF:352×240 (NTSC); 352×288(PAL) |
| D1:720×480(NTSC); 704×576(PAL) |
| 960H:960×480(NTSC); 960×576(PAL) |
| Preview resolution | 960 x 480 ( NTSC ), 960 x 576 ( PAL ); Or : 720×480(NTSC); 704×576(PAL) |
| Playback resolution | D1 x 4 |
| Hexaplex operation simultaneously: | Preview, recording, playback, and network live, backup |
| Hard disk |
| Esata | 1 SATA Hard Disk interface |
| Capacity | Up to 3TB capacity for each disk |
| External interface |
| Network interface | 1 RJ45 Ethernet connector, Static, Dynamic IP and DDNS , Support Internet Explorer and special client software |
| USB interface | 2*USB 2.0 |
| Alarm in/out | NO |
| General |
| Power Supply | 100~240VAC, 47~63Hz, 3A |
| Power Consumption | 67W (including 4-port PoE) |
| Working temperature | -10 °C~ +55 °C |
| Working humidity | 10%~90% |
| Dimension | (L×W×H): 245*215*42(mm) |
| Weight | 1.5kg |
Shenzhen Teamway Technology Co. Ltd, founded in 2008, is a high-tech enterprise that integrates R&D, manufacture and marketing under one roof. Our company manufactures high-quality CCTV products.
Our factory covers over 20, 000 square meters and has more than 800 employees who operate five new SMT production lines, 20 CCTV camera assembly lines, eight modernized DVR production lines and several NVR production lines. Our aim is to become a leading enterprise in commercial security and protection industry. Our products range from waterproof IR cameras, dome cameras, gun cameras, IP cameras, speed dome cameras, DVRs to camera peripherals, such as lens, brackets, housings and more.
Our experienced engineers ensure the top quality of our products as well as high product efficiency with their technologies, such as making stable circuit programs, selecting appropriate elements and accurately grasping test and assembly standards. Manufactured under ISO 9001: 2008-certified guidelines, our products have got international certificates, like CE, FCC and RoHS.
Plenty of high-tech facilities have been applied to production, for instance, dust-free workshop and darkroom (simulating the outdoor no light reflection environment). Advanced testing equipment are also used in production, such as vector oscilloscopes, standard light boxes, imported HR CCTVs, constant temperature ovens, spectrographs, optical imaging projectors, high-low temperature testers and vibrating test benches, which underpin the quality of our products.
We pay special attention to our customers' advice and constantly invest in R&D so as to launch products that can meet the requirements of both domestic and international markets. We collaborate with our customers for a long time and ensure their interests, meet their special requirements and provide complete after-sales service, which have won us great reputation. With skilled staff, strict management and advanced technology, we provide top quality CCTV products to customers all over the world with competitive prices.
Our products sell well in Europe, North and South America, the Middle East, Southeast Asia and Australia. We have established agent and OEM partnerships with a large amount of distributors around the world. Our products have been praised for their high technology, diversification, decent quality and reasonable prices.
Inquire today to begin sourcing.
