| Prod Model: |
XYM-WMYJPJ046 |
Product Description
1. Samsung 46" DID Ultra Narrow Bezel Panel.
2.1.3-2 years warranty.
3. Multi-touch display video Wall solution for advertising.
4. Support VGA, DVI, HDMI and composit inputs.
5. OEM, ODM provider
6. User application: Conference rooms, office building, lobbies, Security Monitoring, Surveillance Retail Dynamic Signage, Restaurant Dynamic Signage, Retail Shopping Mall Advertising and information Displays, Public Installations, Exhibition, Live show, Museums, Transportation and Mass Info Display systems.
Features/Advantages:
A. Super thin bezel: 6.7mm, combining outstanding image performance and most advanced features with an almost frameless design.
B. Support HD 1366X768 resolution. High contrast ratio: 4500: 1, 700CD/m2 high light.
C. Designed and engineered for 24/7/365 operation.
D. Very eco-friendly low power consumption.
E. High brightness panel for installation in high ambient light conditions
F. The maximum number of screens we can configure is 225 units (15X15).
G. Various installation methods: Wall mount, floor mount, cabinet, control consoles etc.
One-stop Solution - design, accessories, installation guide.
| PRODUCT DESCRIPTION |
| Panel |
| Diagonal Size | 46" |
| Aspect Ratio | 16: 9 |
| Pixel Pitch | 0.7455(H) x 0.7455(W) |
| Response Time | < 8ms |
| Resolution | 1366x768 |
| Contrast Ratio | 4500: 1 |
| Brightness (cd/m2) | 700d/m2 |
| Active display area | 1018.353 (H) x 572.54(V) |
| Display Color (Max) | 16.7M |
| Viewing Angle | H: 89o/89o V: 89o/89o |
| Video Input | |
| VGA | X1 |
| DVI | X1 |
| HDMI | X1 |
| Composite video( BNC) | X1 |
| RJ45(use for RS232 IN) | X1 |
| RJ45(use for debug) | X1 |
| Output Connection | |
| Composite video(BNC) | X1 |
| DVI | X1 |
| RJ45(use for RS232 OUT) | X2 |
| Power |
| Power Supply | AC Input 100~240V(+/-10%)/50-60Hz |
| Power Consumpiton | ≤ 210W |
| Stand-by(MAX) | ≤ 2W |
| Operation/Sotrage |
| Operating Temperature | 0 0 C~50 0 C |
| Operating Humidity | 10%~90% |
| Storage Temperature | -20 0 C~60 0 C |
| Operating Humidity | 0%~90% |
| Safety and Ergonomics |
| Regulations | CE, FCC, ROSH |
| Technical Specification |
| OSD language | Simplify Chinese, English |
| Horizontal Frequency | 20 ~ 82KHz(analog and digital) |
| Vertical Frequency | 55~75Hz |
| Optimum Resolution | 1366x768at 60HZ |
| Native Resolution | 1366x768at 60HZ |
| Supported Resolutions | 1366x768; 1280x1024; 1280x768; 1024x768; 832x624; 800x600; 720x400; 600x480; |
| Video Modes(no tuner) | 480i; 480p; 576i; 576p; 720p(50 & 60HZ); 1080i(50 & 60HZ); 1080p(50 & 60HZ); |
| Colour Versions | Black |
| Package Contents |
| Manual | x1 |
| Warranty Card | x1 |
| Application CD | x1 |
| Power Cord | x1 |
| Lan cable(1.8m) | x1 |
| RJ45 to RS232 connector | x1 |
| Batteries | x1 |
| Mechanical Spec |
| Weight(Set/package) | 20kg/25kg |
| Dimension(W/O stand) | 1025.7*579.8*105mm |
| Packing Dimension | 1160x710x240mm |
| Warranty |
| 1 year for backlight, 3 years for other parts |
| Terms And Conditions |
| Payment Term | T/T or Sight L/C |
| Shipment Term | FOB, CIF, CNF |
| Port of Loading: | Shenzhen |
| Brand | Follow Client' s Command (Ours, OEM, ODM) |
| MOQ | 20' ft |
| Valid Date | 7 days |
| Delivery Time | Within 25 Days After payment |
| About Samples |
| Extra 15% Handling Fee Is Charged For Sample. It will Be Returned When An Purchase Order Is Placed |
| Optional Accessories |
| Wall Mount |
| RS232 to USB connector |
| BNC to RCA Adaptor Jack |
| BNC to BNC cable(1.5m) |
| DVI cable(1.5m) |
| HDMI cable(1.5m) |
| VGA to BNC cable(1.5m) |
