| Prod Model: |
PM460DSN |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Diagonal Size: |
46" |
| Aspect Ratio: |
16:9 |
| Pixel Pitch: |
0.53(H) X 0.53(W) |
| Response Time: |
<5ms |
| Resolution: |
1920X1080 |
| Contrast Ratio: |
3000:1 |
| Brightness: |
350CD/M2 |
| Activve Display Area: |
1018(H)X573(V) |
| Display Color: |
16.7m |
| Viewing Angle: |
H:178 Degree V: 178 Degree |
| Screen Size: |
40-50 Inches |
| Remote Control: |
With Remote Control |
| Screen Technology: |
LCD |
| Type: |
Network Version AD Player |
| Application: |
Bus/Car AD Player |
| Installation: |
Wall-Mounted |
| Customized: |
Customized |
Product Description
[Description]
Digital signage of network version is android system. Android online information system based on the Android version 4.0, B/S architecture.System integration with video, pictures, text, web pages, audio playback function, this product USES the mobile phone operating system, and everyone is using smart phones have similarities, easily accepted by users, which can be entertainment, and human-computer interaction, is the real intelligent advertising system.
[Function]
1. support 1920 x1080 high-definition video decoding.
2. built-in 4 gb of memory, can store thousands of sharp image.
3. support SD card expansion, maximum 32 g.
4. pictures and video in no black screen, truly seamless switching.
More than
5. super session timer switch machine, can be set up according to the daily or weekly.
6. built-in multiple transitions model images, images play transitions and interval time can be set freely by the software.
7. can store up to 100 playlists, according to the preset time to play.
8. die portrait as switching.Vertical screen mode through programming tools, video, images, rotate automatically, without the use of third-party tools for editing processing.
9. support screen any split screen, can achieve 1 video + 4 pictures + 1 scrolling marquee date + 1 logo + 1 + 1 + 1 background.
10. U disk broadcast are available, and can also be show in the U dish into the built-in memory for playback.
11. can set the encryption mode, through the programming tools and terminal setting, implementing encryption for the program, without the right key, will not be able to play.
12. and can be set to open mode, copy the media files directly to the U disk root directory, without having to edit, insert U disk directly.
13. support the video formats: MPG, RMVB, AVI, MOV, MP4, RM, TS, etc.
14. and supported image formats: JPG, BMP, PNG, etc.
15. support for scrolling marquee: font color, font size, rolling speed by user-defined Settings.
16. multilingual OSD menu, by default, English, Japanese, French.
17. supports VGA output.
18. obligate infrared human body induction interface, synchronization, GPRS module interface interface, RFID interface.
19. support USB upgrade system and screen.
20. support WIFI,3G,Lan mode.
|
Product Description |
|
LCD panel |
|
|
Diagonal Size |
46" |
|
Aspect Ratio |
16:09 |
|
Pixel Pitch |
0.53(H) x 0.53(W) |
|
Response Time |
8ms |
|
Resolution |
1920X1080 |
|
Contrast Ratio |
3000:1 |
|
Brightness (cd/m2) |
350d/m2 |
|
Active display area |
1018(H)X573(V) |
|
Display Color (Max) |
16.7M |
|
Viewing Angle(U/D,L/R) |
178°(H)/ 178°(V) |
|
System software |
|
|
System software |
Android 4.2.2 |
|
Network mode |
|
|
Lan |
10M/100M |
|
WIFI |
802.11g/n |
|
3G |
Need 3G module |
|
Support format |
|
|
Video format |
MPEG1\MPEG2\MPEG4\H.264\WMV\AVS, VC-1,RV, VP6/VP8, Sorenson Spark, MVC |
|
Audio format |
MP3 |
|
Image format |
JPG\JPEG\BMP\PNG\GIF |
|
Speaker |
|
|
Speaker |
2*5W |
|
Parameters |
|
|
CPU |
Dual Core ARM Cortex A9 1.5GHz |
|
GPU |
4*Core ARM Mali-400 MP |
|
Memory |
DDR3 1Gbyte |
|
SD card |
Max 32G |
|
USB interface |
USB2.0 * 1 |
|
Internal Storage |
FLASH 4G |
|
Audio output |
Stero CLASS-D, Support:8Ω 2x10W |
|
3G module interface |
PCIE*1; USB*1 |
|
WIFI |
WIFI(150Mbps)*1 |
|
Lan |
10/100M |
|
Video output |
VGA×1\HDMI×1 |
|
Audio output |
3.5mm Phone Jack |
|
Extensible interface |
Serial port * 1; SPI *1;Camera * 1;USB(for touch) * 1 |
|
Main function |
|
|
1080p decord |
|
|
Boot automatically play |
|
|
Image automatic stretch and tiled |
|
Support remote control command to the server sends the parsing and processing, including: breaking news, restart terminals, sleep, wake up, forced shutdown, time switch machine, set the volume, the application of the remote online upgrade, set the terminal download speed limit. |
|
RTC real-time clock |
|
|
On/off timer |
|
|
System upgrade(by network or USB) |
|
File encryption:Set by GTV tools and terminal. not playing without the key |
|
Horz/Verti mode |
|
|
Split screen:Video*1, Pic*1,Scrolling text*1,Logo*1,Date*1,Time*1,BG*1 |
|
Scrolling text:custom define font, color, size, speed |
|
Timing play |
|
|
Display the playlist from USB |
|
Update the playlist from USB |
|
Software manage 100 playlist |
|
Video, Picture flash shift |
|
|
26 kinds of patterns, transitions and conversion time ,set by the software |
|
Support multi language( chinese, english) |
|
Repeat mode |
|
|
Power off memory |
|
|
Basic Specification |
|
|
Operation |
Keyboard, Remote control, Net control |
|
Material |
Metal |
|
Color |
Silver frame, Black panel |
|
Technical Specification |
|
|
OSD language |
Simplify Chinese, English |
|
Horizontal Frequency |
20 ~ 82KHz(Anolog&Digital) |
|
Vertical Frequency |
55~75Hz |
|
Optimum Resolution |
1920x1080 at 60HZ |
|
Native Resolution |
1920x1080 at 60HZ |
|
POWER |
|
|
Power supply: |
AC 100~240V(+/-10%)/50-60Hz |
|
Power consumpiton: |
≤250W |
|
Stand-by: |
≤1W |
|
Operation/Sotrage |
|
|
Operating Temperature |
0 0 C~40 0 C |
|
Operating Humidity |
10%~90% |
|
Storage Temperature |
-20 0 C~60 0 C |
|
Storage Humidity |
0%~90% |
|
Safety and Ergonomics |
|
|
Quality standards: |
ISO9001,CCC,FCC,CE,ROHS |
|
Environmental standards: |
All components,accessories and packing are compliant with international standards. |
|
|
|
Optional Function |
|
|
IR body sensor |
GPRS function |
|
Synchronization function |
RFID function |
|
Serial Port module |
Camera |
|
Touch screen |
SPI function |
|
Software |
|
|
GTV |
|
|
Accessories |
|
|
Wall mount(or stand set) * 1 |
Remote control * 1 |
|
User manual *1 |
Power cord * 1 |
|
Mechanical Spec |
|
|
Hole for wall mount: |
/ |
|
NW/GW: |
25kg/30kg |
|
Dimension(W/O stand): |
1117*672*46mm |
|
Packing Dimension (1 pcs/ctn): |
1210*760*150mm |
|
Warranty |
|
|
13 months (LCD monitor and components) |
|
