| Prod Model: |
YC463QU-3DIMH-PC |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Cooling System: |
High Energy Saving Fans Cooling System |
| Luminance: |
2000nits |
| Start-up Quickly: |
Work Stably |
| Naked Eye: |
Clearly Visual HD High Resolution Durable Well-De |
| HD: |
High Resolution |
| Type: |
Network Version AD Player |
| Application: |
Semi Outdoor AD Player |
Product Description
Product Description:
The Glasses-free 3D advertising machine is also called Naked-Eye 3D advertising machine, which means that the lifelike 3D images can be seen without being equipped with any auxiliary facilities (such as 3D glasses, etc. ).
With its incomparable advantages, the 3D Glasses-free advertising machine has become the new choice for enterprises to publish their brands by broadcasting the infinite dynamic 3D ads.
Full range product specification, 7 to 84 inch screen size can be choose.
Excellent compatibility: Proprietary 3D player software is compatible with various 3D formats, including side-by-side view, top-and-bottom view, 8 views, 9 views
Greatly enhance the advertising attention and audience memory degrees, 100% to achieve the effect of advertising.
Product Features:
1: Lcd screen image brightness can be up to more than 3000 lumens (the brightness is better than other similar products about 6 times)
2: Configuration light automatic controller, according to the ambient light automatically adjust the screen image brightness.
3: Can work normally in -20(degree celsius) to + 45(degree celsius) environment.
4: Energy-saving fans cooling system, outdoor use without air conditioning
5: The LCD module adopts LED backlighting modular cooling components + high quality fans group
6: Outdoor all-weather metal case + fans cooling system+ dust filter system
7: : 6mm minus reflection AR protection glass, glass surface without reflection in the sunlight.
YC462WU-3DIM-PC is a fusion of the most high-end technology of liquid crystal display, with full hd widescreen display, constantly bring you quality shock, with excellent flicker-free progressive scan, with the best brightness is gorgeous color. Vivid image to your audience bring extraordinary visual experience.
Up to 120 Hz refresh rate of the panel
120 hz refresh rate to bring more detailed and clear picture quality, less residual shadows. Benefit and this, in ornamental Hi-speed sport video, such as sports or activities the scene, can eliminate in 60 hz blurred images may be produced on the display.
Network control: RS232
Allows the user to remotely through RS232 protocol control and adjust the display.
Network control: RJ45
With the newly introduced RJ45 port, you can more easy to manage your display. The user can through a RJ45 cable configuration display and monitor each parts work state of the equipment.
Intelligent embedded technology
Built-in a industrial control PC.
Automatic brightness control
Can automatically adjust the display brightness by induction ambient light. Constantly enhance the user visual experience of reducing power consumption at the same time.
Wide application range:
Advertising media, exhibition display, scientific research and teaching, games, entertainment, industrial and architectural design, and other areas of the video image.
Display
Screen Size: 46inch
Solution: 1920 x 1080
Brightness: 1500cd/m²(Min)
Response Time(G~G) 8 m/s
Viewing Angle( Horizontal / vertical )178° x 178°
Pixel pitch 0.4845 x 0.4845mm |
Operating conditions
temperature range -20– 45(degree celsius)
relative humidity 5-90% |
Connection:
PC:HDMI
VGA Output D-Sub 15p
RS232 Output D-Sub 9
Signal circuits: VGA,HDMI
Network control: RS232,RJ45
USB*3 USB1.1/2.0
LAN(RJ45)
External speaker |
Power supply
Main power supply : 90-264V AC/50-60DC
|
Speaker
Built-in speaker 2 x 10W |
AV Input:HDMI
S-Video
Element(YPbPr)
Audio(left/right) |
Accessories:
remote control, remote control battery, AC power cord, HDMI HD cable, VGA signal lines, quick start guide. |
Others
Border: grey, black metal
Product certification:CE\FCC |
Product Advantage:
Cooling system: high energy-saving fans cooling system (without air conditioning)
Waterproof, dustproof, moisture, corrosion, mouldproof, shock resistance, resistance to electromagnetic interference
Can be rapid start-up and work stable under the condition of low to minus 25 degrees Celsius
Ambient light automatic brightness adjustment control, (minimum 400 nits( factory Settings) to maximum brightness) |
