| Prod Model: |
YC422WU-3DOMH-PC |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| 42inch: |
3D |
| TFT Panel: |
High Brightness |
| Start-up Quickly: |
Work Stably |
| HD: |
High Resolution |
| Ultra Energy Saving: |
Efficient Heat Dissipation |
| Type: |
TFT |
| Application: |
Big-Screen Project |
| Aspect Ratio: |
16:9 |
| Feature: |
3D Display |
| Screen Size: |
≥28" |
| Interface Type: |
HDMI |
Product Description
Product Description:
？The Glasses-free 3D advertising machine is also called Naked-Eye 3D advertising machine, which means that the lifelike 3D images can be seen without being equipped with any auxiliary facilities (such as 3D glasses, etc. ).
Be vividly portrayed of image and immersive experience, let a person infinite intoxication.
With its incomparable advantages, the 3D Glasses-free advertising machine has become the new choice for enterprises to publish their brands by broadcasting the infinite dynamic 3D ads.
？Products Features
？1: 18.5" to 84" available, special super-slim shape design.
2: Screen brightness reach the highest level in the industry, it can be reach up to？3000nits？or even？4000nits, the image keep visible clearly under the strong light？
3:？Original fans cooling system(without air conditioning), it can realize the maximum energy saving but also greatly extend the service life of the the product.
4.Waterproof, dustproof, moisture, corrosion, mouldproof, shock resistance, resistance to electromagnetic interference
5.Can be rapid start-up and work stable under the condition of low to minus 25 degrees Celsius？
6.Outdoor all-weather metal case + fans cooling system+ dust filter system
7.Professional LCD backlight optical enhancement technique with high efficiency, excellent optical display properties,？good ontology heat conduction performance.
8.Configuration light automatic controller, according to the ambient light automatically adjust the screen image brightness.
9.Can work normally in？-20 ？to + 45 (degree Celsius)？environment.
10.Professional, standardized products serious and？provide professional customized service
1920 x 1080p？？
YC422QU-3DIM-PC？is a fusion of？the most high-end technology of liquid crystal display, with full hd widescreen display, constantly bring you quality shock, with excellent flicker-free progressive scan, with the best brightness is gorgeous color.Vivid image to your audience bring extraordinary visual experience.
Up to 120 Hz refresh rate of the panel
120 hz refresh rate to bring more detailed and clear picture quality, less residual shadows. Benefit and this, in ornamental Hi-speed sport video, such as sports or activities the scene, can eliminate in 60 hz blurred images may be produced on the display.
？
Network control:RS232
Allows the user to remotely through RS232 protocol control and adjust the display.
Network control:RJ45
With the newly introduced RJ45 port, you can more easy to manage your display. The user can through a RJ45 cable configuration display and monitor each parts work state of the equipment.
Intelligent embedded technology
Built-in a industrial control PC.
Automatic brightness control
Can automatically adjust the display brightness by induction ambient light. Constantly enhance the user visual experience of reducing power consumption at the same time.
Wide application range:
Advertising media, exhibition display, scientific research and teaching, games, entertainment, industrial and architectural design, and other areas of the video image.
Warranty & Service
1. The warranty time is 12 months .
2. We guarantee that each unit is tested carefully and works very well before shipment. We strive for 100%？
customer satisfaction on every sale we complete.
3. During the warranty period, we can repair or replace the defective unit for free, after the warranty time,？
we repair the defective unit and charge part cost.
4.When you receive the package, please open and check it before signing, if it's damaged, ask a？
"Damage proof" from the delivery company.
5.Any question,please contact us by email or Trade Manager, emails will be responsed within 12 working？
hours.
？
Display
Screen Size: 42inch
Solution: 1920 x 1080
Brightness: 2000cd/m²(Min)
Response Time(G~G) 8 m/s
Viewing Angle( Horizontal / vertical )178° x 178°
Pixel pitch 0.4845 x 0.4845mm |
Operating conditions
temperature range : -20 – 45(degree Celsius)
relative humidity 5-90% |
Connection:
PC:HDMI
VGA Output D-Sub 15p
RS232 Output D-Sub 9
Signal circuits: VGA,HDMI
Network control: RS232,RJ45
USB*3 USB1.1/2.0
LAN(RJ45)
External speaker |
Power supply
Main power supply : 90-264V AC/50-60DC
|
Speaker
Built-in speaker 2 x 10W |
AV Input:HDMI
S-Video
Element(YPbPr)
Audio(left/right) |
Accessories:
remote control, AC power cord, HDMI HD cable, VGA signal lines, quick start guide. |
Others
Border: grey, black metal
Product certification:CE\FCC |
Product Advantage:
Brightness: 2000nits(image keep visible clearly under the strong sunlight)
Cooling system: high energy-saving fans cooling system (without air conditioning)
Waterproof, dustproof, moisture, corrosion, mouldproof, shock resistance, resistance to electromagnetic interference.
Can be rapid start-up and work stable under the condition of low to minus 25 degrees Celsius
Ambient light automatic brightness adjustment control, (minimum 400 nits( factory Settings) to maximum brightness). |
