| Prod Model: |
D41000 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Color: |
Black |
| Height: |
1u |
| Certificate: |
CE |
| Type: |
Professional Amplifier |
| Used For: |
Professional |
| Tube Type: |
IC Amplifier |
| Function: |
Post Amplifier |
| Sound Channel: |
4.1 |
| Output Number: |
4 |
| Conductive Mode: |
D |
| Usage: |
Show Events |
| Voltage: |
AC100V~220V |
Product Description
1U digital amplifier with good performance! Mostly used for outdoor events,shows concerts etc.
PARAMETER
Model
Q4650
Q41000
Q41200
Stereo Power rms
8Ω
4x650W
4x1000W
4x1200W
4Ω
4x1200W
4x1800W
4x2100W
2Ω
4x2000W
4x3000W
4x3600W
THD+N
Rated power,THD=1%,1KHZ<0.06%
Max output voltage
97V
Crosstalk(1kHz,typical)
-70dB
Controlled slew rate
50V/us
Input sensitivity
1Vrms
THD
0.05%
IMD-SMPTE
0.05%
Frequency response
0~2dB
Input impedance
balanced 20kΩ,unbalanced 10kΩ
(W×D×H)mm
483x370x44
Damping factor over
≥200
Signal to noise ratio(A weighted,20Hz-20kHz)
≥105dB
Power Requirements
AC~100-240V(50-60HZ)
Protection
Over heat protection/temperature power control/output current
Control/overload protection/power output DC protection
Net weight
8.15KG
