| Prod Model: |
LR-3T |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Cooling Style: |
Water-Cooling |
| Refrigerant: |
R22 |
| Compressor: |
Germany Bitzer |
| Ice Thickness: |
1.5-2.2mm |
| Ice Temperature: |
-5~-8 Centigrade |
| Standard Power Supply: |
3p/380V/50Hz |
| Unit Measurement: |
3100mm*2160mm*2265mm (L*W*H) |
| Unit Net Weight: |
2940kg |
| Working Noise: |
Below 70dB |
| Certification: |
SGS |
| Condition: |
New |
| Ice Shape: |
Flake Ice |
Product Description
(1)Flake ice:
Flake ice is made of the mixture of brine and water (Max. 500g salt per ton of water), in some cases can be directly made from brine water. Thickness between 1mm-3mm, irregular shape with diameters from 12mm to 45mm. Flake ice has got property of outstanding refrigeranting effect. In cooling process, flake ice is the quickest than any other ices
Various models to meet all your demands: Lier flake ice machine daily output ranges ranges from 200kg to 60, 000kg per day. Single-phase and three-phase power is available to meet all customers' demand. (Condenser of the machines mentioned above can be installed outside or separated according to the customers' requirements. )
Evaporator is made of imported SUS304 or carbon steel with high heat transfer efficiency, whose surface is Nobelium electroplated. The material can ensure the ice burrel excellent corrosion resistant and flake ice clean and hygiene.
Advanced technology: Our flake ice machine evaporator uses annealing heat treatment furnace and vibration aging process to eliminate the welding stress. It can prevent the evaporator inner wall from deformation and eventually prolong the evaporator working life.
Features and advantages of Flake ice:
1. Large contact area: As its flat and thin shape, it has got the largest contact area among all types of ice. The larger its contact area is, the faster it cools other stuff. In comparison with 1 ton of cube ice, 1 ton of flake ice has 1799 sqm of contact area while 1 ton of cube ice only has 1383 sqm, therefore the flake ice has got much better cooling effects than cube ice.
2. Low cost of producing
The producing of flake ice is very economical, it only requires 1.3RT refrigerating effect to make 1 ton of ice from 16C water.
3. Perfect in food cooling
Flake ice is type of dry and crispy ice, it hardly forms any shape edges, in food cooling process, this nature has made it the best material for cooling, it can reduce the possibility of damage to food to the lowest rate.
4. Thoroughly mixing
Flake ice can become water quickly through the rapid heat exchanging with products, and also supply the moisture for products to be cooled.
5. Convenient for delivery
Because the flake ice fairly dry, it will not stick with others during delivery or storage.
|
Style |
Capality |
Total Power |
Power of Reducing |
Power of Pump |
Overall Size(mm) |
Weight |
|
LRD-05T |
0.5t/d |
0.32kw |
0.18kw |
0.12kw |
810*700*780 |
120kg |
|
LRD-1T |
1t/d |
0.32kw |
0.18kw |
0.12kw |
810*700*880 |
160kg |
|
LRD-1.5T |
1.5t/d |
0.32kw |
0.18kw |
0.12kw |
810*700*980 |
180kg |
|
LRD-2T |
2t/d |
0.5kw |
0.37kw |
0.12kw |
930*850*1108 |
230kg |
|
LRD-3T |
3t/d |
0.5kw |
0.37kw |
0.12kw |
930*850*1200 |
255kg |
|
LRD-4T |
4t/d |
0.57kw |
0.37kw |
0.18kw |
1150*1000*1200 |
310kg |
|
LRD-5T |
5t/d |
0.57kw |
0.37kw |
0.18kw |
1150*1000*1300 |
340kg |
|
LRD-6T |
6t/d |
0.57kw |
0.37kw |
0.18kw |
1150*1000*1300 |
380kg |
|
LRD-8T |
8t/d |
0.95kw |
0.75kw |
0.18kw |
1720*1410*1560 |
850kg |
|
LRD-10T |
10t/d |
0.95kw |
0.75kw |
0.18kw |
1720*1410*1700 |
1050kg |
|
LRD-12T |
12t/d |
1.2kw |
0.75kw |
0.18kw |
1720*1410*1850 |
1140kg |
|
LRD-15T |
15t/d |
1.2kw |
0.75kw |
0.37kw |
2100*1900*1860 |
1500kg |
|
LRD-20T |
20t/d |
1.2kw |
0.75kw |
0.37kw |
2100*1900*2050 |
1800kg |
|
LRD-25T |
25t/d |
1.2kw |
0.75kw |
0.37kw |
2100*1900*2260 |
2100kg |
|
LRD-30T |
30t/d |
1.89kw |
1.5kw |
0.37kw |
3100*2400*2350 |
2250kg |
Shenzhen Liermachine Refrigeration Equipment Co., Ltd. is a professional and leading supplier of ice making machines and refrigeration equipment. We focus on the development, production, marketing, installation and repairing services of ice machines.
With advanced technology, modern management, strict quality control, skilled workers and professional services, our ice machines are widely welcomed by customers from at home and abroad.
We produce flake ice machines, tube ice machines, block ice machines, cube ice machines, plate ice machines and some related machine parts. We have different styles of ice making machines for different using fields. Our products are widely applied in aquatic product storage, fruit or vegetable preservation, meat processing, medicine and chemical refrigeration, textile printing and dyeing industry, deep sea fishing, laboratory refrigeration, concrete pouring and cooling, and so on. Lier always provides reasonable and efficient solutions and makes the best ice machines to meet the demands of customers.
"Endless innovation for technology, continuous improvement for service" is our slogan. We will cooperate with all customers, following the "professional, honest and win-win" spirit.
