| Prod Model: |
PAL30 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Dimensions(W*H*D): |
210mm * 94mm * 276mm |
| Weight: |
3.9kg |
| Rated Power: |
30W |
| Function: |
Amplifier Combined |
| Used For: |
Professional |
| Tube Type: |
Transistor Amplifier |
Product Description
Product description
PAL30 is the high performance audio amplifier which are designed for commercial and industrial public address applications. This type is the standard mount design, rated power is 15W,30W to provide a wide selection for different sound system. Both balanced and unbalanced line inputs are selectable, 4Ω,25V,70V output terminal are selectable for different speaker installation matching. Complete protection includes short circuit, overload and overheat automatic protection.
Features
1. standard mount design, humanistic design, exquisite technique, show the top grade quality
2. 15W,30W output power
3. 4Ω or 8Ω output terminal
4. 4 line selection
5. balanced input
6. high and low tone control and sound control
Application and management
Applied in airport, station, coffee shop, market, square, school, park, district and other places.
Port allocation:
Balanced or RCA input, 4Ω,25V,70V output terminal multi-impedance output
Specification
Model
PAL30
Power requirement
110-125V AC or 220V-230V AC,50/60Hz
Rated power
30W
Distortion
Less than 1% at 1 kHz
Frequency Response
50~20,000Hz(±3dB)
Tone control:
Bass:±10dB at 100Hz/Treble:±10dB at 10KHz
Output
Line 1:
0dB, 600Ω Unbalanced,RCA pin jack
Speaker selection output:
8Ω at 1.5 Watts
Direct output:
High Impedance:70V\25V screw terminal
Low Impedance:8Ω screw terminal
Inputs
TEL:
0.316 ~ 3.16mV (-50 ~ -30dBV) balanced Phenix Input
AUX 1:
316mV (10dBV) 10kΩ Unbalanced RCA Summing Line
Operating Temperature
-10 to +40
Color
black
Dimensions(W*H*D):
210mm * 94mm * 276mm
Weight
3.9kg
