| Prod Model: |
LD320.240_035_9_B700 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type: |
Color |
| Display Technology: |
TFT |
| Usage: |
Small-sized LCM |
Product Description
This product is a 3.5inch rugged small-sized with high resolution military LCD display, Backlight part adopts high brightness LED sources, which is high reliability and long service life. Brightness can be adjusted from 10cd/m² to 700cd/m².Display part adopts self-developed control card processor based on ARM920T chip system, which frequency is 200MHs,have MMU inside,16KB instruction,16KB data and Maverick Crunch Math co-processer. Supporting hardware floating point arithmetic and 2D drawing function, A variety of bitmap fonts, and RS232 or RS422 communication, Vibration and shock meet the standard of GJB150-1986, EMC meet the relative provision of GJB151A-1997.
|
Model No. |
LD320.240_035_9_B700 |
|
resolution |
320*240 |
|
touch specs (optional) |
4 lines resistive touch screen (RS232 Interface)
|
|
Active Image area |
78.6×53.5mm |
|
Outline dimensions |
customize |
|
Brightess |
>=700 |
|
Contrast ratio |
150:1 |
|
Contrast ratio(shimmer night vision) |
>3.27:1 107000Lux |
|
Specular reflectance |
<1% |
|
Brightness uniformity |
≤20% |
|
Viewing envelope (CR >5:1) |
±120° H ±100° V |
|
Signal input |
LVDS or TTL |
|
Power supply |
DC12V |
|
Power consumption |
normal temperature power consumption≤9W, |
|
Weight |
≤0.65kg |
|
Work temperature |
-45degree celsius-60degree celsius |
|
Storage temperature |
-55degree celsius-70degree celsius |
Vibration
|
meet GJB150.16-1986 airborne requirements |
Shock
|
meet GJB150.18-1986 airboren requirement |
Berise Technology (Shenzhen) Limited, is a Hi-Tech company specializing in producing High Brightness LED Backlight LCD, optics binding, LCD panel cutting technology and the other general reinforcement technique etc.
Products are mainly divided into two categories: outdoor advertising and military reinforcement displays
In outdoor display, The products of our company all used the top High Brightness LED backlight module and DID splicing techniques breaking the monopoly of foreign technology and making the popularity of home-based LED possible.
Now we have the patents in controlling the core technologies of the backlight module. We all inherit the management philosophy of "Rise in Shenzhen, Service the global"and innovate continuously for excellence in technique and service. We are making every effort to become the most powerful and the most effective enterprise in the LED backlight field. Because of the hi-quality and high-rank displaying effect, our products received a considerable acclaim. And we also have estabished a good partnership with some major industry, e. G. TCL and Zhuhai Satow ect
In military reinforcement display products, after years of development, has a number of patented technologies, products cover a wide range, meet the requirements of multiservice to display products
optics binding and optical coating technology, can greatly improve the visibility of the display product in the sun, product vibration resistance and the characteristics of low pressure, at the same time can prevent the inside the product of the fog; Independent research and development of the LCD panel cutting technology, and is not restricted by space, according to the customer request custom display screens of all sizes; LED backlight technology, expanding the product color gamut space, improves the performance of vibration resistance, improves temperature characteristics of the product LED; high-performance, high-bandwidth military board technology, adopted FPGA research and development of IP technology, which can realize the 2 D / 3 D graphics generation, it can realize pip, pop, color key, overlay drafting, Image fusion such as a variety of display mode, can support up to 4090 * 2048 resolution
