| Prod Model: |
BCD176 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Item: |
Home DC 12V Refrigeration Compressor Solar Refrig |
| Color: |
Gray |
| Power Consumption: |
72W |
| Input Voltage: |
DC 12V/24V Auto Recognition |
| Fridge Capacity: |
116L (2.68 C.F.) (Bottom) |
| Freezer Capacity: |
60L (1.48 C.F.) (Upper) |
| Product Size(mm) (L*W*H): |
500*530*1450mm |
| Carton Size(mm) (L*W*H): |
555*605*1505mm |
| N.W./G.W.(Kg): |
43/47 |
| Warranty Time: |
3years |
| Capacity: |
60-200L |
| Door: |
Double Doors |
| Installation: |
Free-Standing |
| Type: |
Bottom-Freezer |
| Power Source: |
Solar |
| Material: |
Plastic |
| Temperature Type: |
Single-Temperature |
| Defrost Type: |
Manual Defrost |
| Climate Type: |
T |
| Certification: |
CE |
Product Description
Advantages:
*Fully hermetic domus compressor with integrated control electronics.
*Automatically turn off when low input voltage to prodect product
*Connect with DC power source directly e.g solar power source
*Connect with AC power source through an AC/DC adaptor,connect with solar freezer
*High temperature resistance design and energy saving design
*With single top door and door lock
*Enviroment-friendly refrigerant R134a
2015 new design
High quality
2016 china DC 12V 24V Solar Refrigerator
2016 china DC 12V 24V Solar Refrigerator
Features
Ø No AC Inverter Needed |
Ø Input voltage automatic recognition |
Ø Environmental friendly CFC-free refrigerant (R-134a) |
Ø Using AC power through AC/DC adaptor |
Ø Low power consumption makes best use of available power |
Ø 0°C-10°C (32°F-50°F) for
refrigerator compartment |
Ø Low voltage cut out automatically to protect batteries |
Ø High temperature resistance and energy saving design |
Ø Max -18°C (-0.4°F) for freezer compartment at 30°C (86°F) Ambient temperature |
*******************************************************************************************************************
2016 china DC 12V 24V Solar Refrigerator
Specification
solar refrigerator
Model | BCD 92 | BCD 118 | BCD 142 | BCD 158 | BCD 176 | BCD198 |
| Power Consumption | 60W | 72W | 72W | 72W | 72W | 72W |
| Input Voltage | DC 12V/24V |
| Work Temperature | <40ºC |
| Capacity | Fridge Capacity | 82L (2.90 c.f.) | 76L (2.68 c.f.) (Bottom) | 100L (3.53 c.f.) (Bottom) | 98L (3.46 c.f.) (Upper) | 116L (4.10 c.f.) (Upper) | 118L (4.17 c.f.) (Upper) |
| Freezer Capacity | 10L (0.35 c.f.) | 42L (1.48 c.f.) (Upper) | 42L (1.48 c.f.) (Upper) | 60L (2.12 c.f.) (Bottom) | 60L (2.12 c.f.) (Bottom) | 80L (2.83 c.f.) (Bottom) |
| Product Size (mm) | 470 × 475× 815 | 470× 475 × 1165 | 470× 475× 1265 | 500 × 530 × 1370 | 500× 530× 1450 | 500× 530× 1580 |
| Carton Size (mm) | 505× 535 × 855 | 505× 535× 1205 | 505 × 535 × 1305 | 555 × 605× 1430 | 555× 605× 1505 | 555× 605× 1680 |
| N.W./G.W.(KG) | 23/26 | 30/33 | 32/35 | 41/45 | 43/47 | 44/49 |
| Loading Quantity | 88PCS/20GP, 184PCS/40GP, 276PCS/40HQ. | 44PCS/20GP, 92PCS/40GP, 184PCS/40HQ. | 44PCS/20GP, 92PCS/40GP, 184PCS/40HQ. | 38PCS/20GP,
79PCS/40GP, 79PCS/40HQ | 38PCS/20GP,
79PCS/40GP, 79PCS/40HQ | 38PCS/20GP,
79PCS/40GP, 79PCS/40HQ |
solar freezer
| Model | BR90C4 | BR118C4 | BR138C4 | BR188C4 | BR238C4 | BR318C4 |
| Power Consumption | 60W | 72W | 72W | 72W | 80W | 80W |
| Input Voltage | DC 12V/24V |
| Work Temperature | <40ºC |
| Capacity | 90 L (3.18 c.f.) | 118 L (3.18 c.f.) | 138 L (4.87 c.f.) | 188 L (6.64 c.f.) | 238 L (8.40 c.f.) | 318 L (11.23 c.f.) |
| Product Size(mm) | 625× 555× 910 | 815× 555× 910 | 815× 555× 910 | 875× 595× 920 | 1245× 660× 920 | 1245× 660× 920 |
| Carton Size(mm) | 685×565 × 935 | 885×560 × 930 | 885× 575× 930 | 930× 605× 940 | 1300× 680× 940 | 1300× 680× 940 |
| N.W./G.W.(KG) | 26/31 | 29/35 | 30/36 | 36/43 | 50/58 | 52/60 |
| Loading Quantity | 66PCS/20GP,
138PCS/40GP, 138PCS/40HQ. | 52PCS/20GP,
104PCS/40GP, 104PCS/40HQ. | 52PCS/20GP,
104PCS/40GP,
104PCS /40HQ. | 42PCS/20GP,
88PCS/40GP, 88PCS/40HQ | 34PCS/20GP, 70PCS/40GP, 70PCS/40HQ | 26PCS/20GP, 54PCS/40GP, 54PCS/40HQ |
******************************************************************************************************************
