| Prod Model: |
DX5000-II |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Function: |
Removing Hazardous Substances |
| Air Infelt Interface: |
90mm |
| Input Voltage: |
AC 110V-220V |
| Power: |
330W |
| Noise: |
60db |
| Filter Effiency: |
0.3um99.97% |
| Certificate: |
CE and Pony |
| Application: |
Laser, Marking, and Soldering Station |
| Weight: |
31kg |
| Structure: |
Portable |
| Usage: |
Industry |
| Air Volume: |
301-400m³/h |
| Type: |
HEPA Filter |
| Certification: |
RoHS |
| Application Area: |
11-20m² |
| Power Source: |
Electrical |
| Operating Principle: |
Active + Passive |
| Purifying Technology: |
HEPA |
Product Description
2015 welding fume extractor,DX5000-II air purifier,450W Soldering fume extraction
Application:
1. Dust absorbing, smog, Scraps collection
2. Soldering welding, reflow soldering, wave-soldering
3. Laser, Marking, Cutting, engraving, Sculpture
4. Electric welding, soldeing and moxa-moxibustion, Fire therapy.
Features of DX5000-II smoke purifying filter:
1,Integrated body design, structured with metal framework and processed with electrostatic spraying for premium cold-rolled steel sheet, is corrosion-resistant, environment-friendly and durable.
2,Four-stage purification design: filtering step by step enables harmful smoke to be better purified. Even for objects at least 8 times smaller than PM2.5, the purification rate can reach up to 99.97%.
3,This product has the 1.4m universal smoke suction arm, which can be positioned and oriented arbitrarily (its length may be regulated according to customer requirements, without the support of external force). (A patent application has been filed.)
4,Adopt DC brushless motor that has stable performance and long service life. Low noise, high efficiency, low energy consumption, zero maintenance and zero consumable.
5,CE and PONY certified, safe and reliable.
Operating-Principle Diagram of smoke absorber:
1.(Smoke, dust, powder)
→
2. Primary filtering (Large particles of oxides)
→
3. Medium- efficient filtering (About 50um particle oxides)
→
4. High-efficient filtering (About 0.3 um small particle oxides)
→
5. Clean air
Specification parameters of smoke absorber:
Inlete |
voltage |
power |
Filtering effect |
Noise |
Systemic flow |
Contour dimension |
Weight |
φ75mm |
AC 110-220V |
450W |
0.3μm99.97% |
<70dB |
500m³/h |
550*415*920 |
60Kg |
