| Prod Model: |
ASW-10KW/Q1 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Power Supply: |
380~415V/50Hz |
| Refrigerant: |
R410A |
| Heat Temperature: |
50-70??C |
| Work Environment: |
Low-temperature Heat Pump |
| Heat Source: |
Air-source |
| Application: |
Beauty Salons |
| Certification: |
RoHS |
Product Description
2015 NEW air to water split heat pump water heaterProduct description1. Designed as Split Type , Indoor Unit and Outdoor Unit be Connected by Copper pipe,Installation With Simple,Flexible and Conveniently ,The Indoor Unit can be Installed in Kitchen, Bathroom or basement, Ensuring less Energy loss, Also Prevent Water Pipes From Freezing in Cold Winter and sun Exposure in hot Summer.
2. Indoor Unit Mainly Components Includes:Plate Heat Exchanger,Controller,Cycle water Pump,Differential Pressure Flow Switch,Electric Three Way Valve, Auxiliary Heating and so on parts.
3. Outdoor Unit Mainly Components Includes:Compressor,Evaporator,Additional Plate Heat Exchanger,Controller,Expansion Valve,Four way valve,Motor,Refrigerant valve and De-Ice Heater so on parts.
4. With R410A Refrigerant Brand EVI Low Temp Scroll Type Compressor ,R407C Refrigerant Brand EVI Low Temp Scroll Type Compressor ,Green Environment, High-Efficiency,Providing Wonderful Performance and Reliability.
5. Operating Steadily under -25°C~45°C Ambient temp ,for Cold Regions Heating in Winter, or Cooling in Summer, and Supply Domestic Hot Water at same time.
6. Test conditions: The above data is tested by EN14511;
7.Rated Heating Capacity Measuring conditions:Ambient Air temp (DB/WB):7ºC/6ºC,Water inlet 30ºC,Water outlet 35ºC;
8.Rated Cooling Capacity Measuring conditions:Ambient Air temp (DB/WB):35ºC/24ºC,Water inlet 12ºC,Water outlet 7ºC;
9.Rated Hot Water Capacity Measuring conditions: Ambient Air temp (DB/WB):20ºC/15ºC,Water inlet 15ºC,Water outlet 55ºC;
| Model | ASW | 10KW/Q1 | 13KW/Q1 | 22KW/Q1 | 10KW/Q2 | 13KW/Q2 |
| Power Supply | Ph/V/Hz | 3Ph/380~415V/50Hz | 1Ph/220~240V/50Hz |
| Refrigerant | Type | R410A | R407C |
| Heating | Heat Output (at 7ºC/35ºC) | kW | 10.5 | 13.3 | 21.6 | 10.6 | 13.3 |
| Heat Output (at 7ºC/45ºC) | kW | 10.2 | 12.8 | 21 | 10.3 | 12.8 |
| Heat Output (at 2ºC/35ºC) | kW | 9.2 | 11.7 | 18.4 | 9.3 | 11.7 |
| Heat Output (at 2ºC/45ºC) | kW | 8.9 | 11.3 | 17.9 | 9.1 | 11.3 |
| Heat Output (at -7ºC/35ºC) | kW | 7.3 | 9.3 | 14.7 | 7.4 | 9.3 |
| Heat Output (at -7ºC/45ºC) | kW | 7.1 | 8.9 | 14.2 | 7.2 | 9 |
| Heat Output (at -15ºC/35ºC) | kW | 6.2 | 7.7 | 12.5 | 6.1 | 7.6 |
| Heat Output (at -15ºC/45ºC) | kW | 6.3 | 7.8 | 11.9 | 6.2 | 7.7 |
| Heat Output (at -25ºC/35ºC) | kW | 5.3 | 6.5 | 10.5 | 5.4 | 6.6 |
| Rated input power | kW | 2.69 | 3.46 | 5.6 | 2.71 | 3.5 |
| COP | w/w | 3.9 | 3.84 | 3.86 | 3.91 | 3.8 |
| Auxiliary Electric Heating | kW | 3 |
| Cooling | Cooling Capacity | kW | 8.9 | 11.4 | 18.4 | 8.8 | 11.6 |
| Rated input power | kW | 3.06 | 3.97 | 6.28 | 3.14 | 4.14 |
| EER | w/w | 2.91 | 2.87 | 2.93 | 2.8 | 2.8 |
| Hot Water | Heat Output | kW | 12.2 | 16 | 25.9 | 12.4 | 15.9 |
| Rated input power | kW | 2.84 | 3.7 | 5.88 | 2.95 | 3.78 |
| COP | w/w | 4.3 | 4.32 | 4.4 | 4.2 | 4.2 |
| Compressor | Type | EVI Scroll |
| Heating Hot Water Temp | ºC | 18ºC~65ºC |
| Domestic Hot Water Temp | ºC | 30ºC~60ºC |
| Cooling Water Temp | ºC | 8ºC~18ºC |
| Operating outdoor temperature limit | ºC | -25ºC~45ºC |
| Indoor Unit | Noise Level | dB(A) | 33 | 34 | 36 | 33 | 34 |
| Net Weight/Gross Weight | kg | 37/42 | 38/43 | 41/46 | 37/42 | 38/43 |
| Net Dimension(H*W*D) | mm | 695*520*256 |
| Packing Dimension(H*W*D) | mm | 795*610*405 |
| Outdoor Unit | Noise Level | dB(A) | 53 | 54 | 58 | 53 | 54 |
| Net Weight/Gross Weight | kg | 110/125 | 113/128 | 180/198 | 115/130 | 146/158 |
| Net Dimension(H*W*D) | mm |
| 1335*910*345 | 1467*1145*420 |
| 1335*910*345 |
| Packing Dimension(H*W*D) | mm |
| 1485*995*425 | 1620*1250*500 |
| 1485*995*425 |
Company informationAKL ELECTRIC CO.,LTD,Founded in 2002, It is a Modern and Enterprises,Professional Manufacturing Air to Water Heat Pump, DC Inverter Heat Pump and Air Conditioner,It is located in Chinas Home Appliances Manufacturing Base, China's Second largest Port City- Ningbo. The company has the advanced product performance laboratory and perfect inspection equipment for production. The person in charge with technical development and quality management are all the professionals from the industry, so we have the stronger abilities of technical development and quality management. We pass the international quality certificates like CCC,CE,SASO, ISO-9001,ISO-1400, ROHS etc.
FAQ Q1:What's the warranty of your heat pump?
A1: Our warranty is complete unit for 1 year and compressor for 3 years.
Q2:Can you allow trail order firstly?
A2:Of course,small order also can be allowed.
Q3:What kind of certification do you have for your heat pump?
A3:We have CCC,CE,ROHS,EMC,ISO9001 for our heat pump.
Q4:Can you export your heat pump?
A4:Yes,above 90% are exported.
We all welcome to your inquiry.
Looking forward to establish a good friendship and cooperation with you.
NINGBO AKL-Histar Electric Co., Ltd was founded in 2004. Main products consist of various electric appliance, and more than 70 kinds in all. with complete specifications, novel models, products are extensively applied to home and commercial department. Our products export to the whole world. Europe, South & North America, Southeast Asia, Africa and Middle East. Our factory obtains reliance and praise from customers and societies with excellent quality and competitive price.
Our company has passed CE, RoHS. COC, SAA. SONCAP. UL. SASO Certificate. For purpose to control products' quality well, we develop a whole set of standard testing equipment by ourselves.
We always insist on the management aim of "quality first, customers supreme", strive for top grade products and offer first rate service. We sincerely welcome the old and new customers to visit our factory, negotiate business, cooperate extensively and achieve common prosperity.
