Prod Model: |
QZB-XXT |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Refrigerant: |
R22/R404A |
Input Power: |
3pH 380V/50Hz |
Ambient Temperature: |
35 |
Inlet Water Temperature: |
16 |
Ice Production Time: |
2-12hours |
Weight Of Ice Block: |
5kgs/10kgs/20kgs/25kgs |
Usage: |
for Manufacture, for Refrigerate |
Cooling Method: |
Direct Cooling |
Ice Shape: |
Ice Block |
Condition: |
New |
Product Description
Brine system block ice machine for making block ice
1. Ice daily capacity: 1-10ton per day
2. Brine system need to use brine tank
3. Block ice: 5, 10, 20, 25kgs
Weight | Model | Cooling capacity | Daily output (kgs) | Ice block size(mm) | Input power (kw) | Power | Refrigerant | Machine Size(mm) |
5kgs | (Make ice in 12 hours) |
QZB-305F12 | 30PCS/5KGS | 300 | 160*80*460 | 1.7 | 380Vor220V/50HZ | R22 | 2200*680*730 |
QZB-505F12 | 48PCS/5KGS | 480 | 160*80*460 | 2.2 | 380Vor220V/50HZ | 2200*1020*730 |
QZB-1005F12 | 99PCS/5KGS | 990 | 160*80*460 | 4.4 | 380V/50HZ | 3400*1100*730 |
QZB-2005F12 | 198PCS/5KGS | 1980 | 160*80*460 | 8.9 | 380V/50HZ | 5800*1100*710 |
(Make ice in 8 hours) |
QZB-305F08 | 30PCS/5KGS | 450 | 160*80*460 | 2.1 | 380Vor220V/50HZ | R22 | 2200*680*730 |
QZB-505F08 | 48PCS/5KGS | 720 | 160*80*460 | 3.1 | 380Vor220V/50HZ | 2200*1020*730 |
QZB-1005F08 | 99PCS/5KGS | 1485 | 160*80*460 | 5.2 | 380V/50HZ | 3900*1100*730 |
QZB-2005F08 | 198PCS/5KGS | 2970 | 160*80*460 | 11 | 380V/50HZ | 5800*1100*710 |
(Make ice in 12 hours) |
QZB-305F06 | 30PCS/5KGS | 600 | 200*60*460 | 3 | 380Vor220V/50HZ | R22 | 2200*680*730 |
QZB-505F06 | 50PCS/5KGS | 1000 | 200*60*460 | 4.2 | 380V/50HZ | 2200*1020*730 |
QZB-1005F06 | 99PCS/5KGS | 1980 | 200*60*460 | 7.2 | 380V/50HZ | 3900*1100*730 |
QZB-2005F06 | 198PCS/5KGS | 3960 | 200*60*460 | 13.2 | 380V/50HZ | 5800*1100*710 |
(Make ice in 6 hours) |
QZB-305F04 | 30PCS/5KGS | 900 | 160*80*460 | 4.6 | 380Vor220V/50HZ | R22 | 2200*680*1100 |
QZB-505F04 | 50PCS/5KGS | 1500 | 160*80*460 | 7.3 | 380V/50HZ | 2200*1020*1100 |
QZB-1005F04 | 99PCS/5KGS | 2970 | 160*80*460 | 13.6 | 380V/50HZ | 3900*1100*1100 |
(Make ice in 4 hours) |
QZB-305F03 | 30PCS/5KGS | 1200 | 200*60*460 | 6.3 | 380Vor220V/50HZ | R22 | 2200*680*1100 |
QZB-505F03 | 50PCS/5KGS | 2000 | 200*60*460 | 8.6 | 380V/50HZ | 2200*1020*1100 |
QZB-1005F03 | 99PCS/5KGS | 3960 | 200*60*460 | 14.8 | 380V/50HZ | 3900*1100*1100 |
(Make ice in 2 hours) |
QZB-305F02 | 30PCS/5KGS | 1800 | 200*60*460 | 8 | 380V/50HZ | R22 | 2200*680*1100 |
QZB-505F02 | 50PCS/5KGS | 3000 | 200*60*460 | 10.6 | 380V/50HZ | 2200*1020*1100 |
| (Others big size block ice) |
10kgs | QZB-5010F12 | 48PCS/10KGS | 960 | 165*80*800 | 4.4 | 380V/50HZ | R22 | 2200*1100*1100 |
QZB-10010F12 | 96PCS/10KGS | 1920 | 165*80*800 | 8.9 | 380V/50HZ | 3800*1100*1100 |
QZB-5010F04 | 48PCS/10KGS | 2880 | 165*80*800 | 7.2 | 380V/50HZ | 2200*1100*1100 |
QZB-5010F06 | 48PCS/10KGS | 1920 | 165*80*800 | 7.2 | 380V/50HZ | 2200*1100*1100 |
15kgs | QZB-5015F12 | 48PCS/15KGS | 1440 | 175*120*800 | 4.4 | 380V/50HZ | 3100*1100*1100 |
QZB-10015F12 | 96PCS/15KGS | 2880 | 175*120*800 | 8.9 | 380V/50HZ | 3800*1100*1100 |
QZB-5015F06 | 48PCS/15KGS | 2880 | 175*120*800 | 9.6 | 380V/50HZ | 4000*1100*1100 |
20kgs | QZB-5020F12 | 48PCS/20KGS | 1920 | 230*120*800 | 7.1 | 380V/50HZ | 3800*1100*1100 |
QZB-10020F12 | 96PCS/20KGS | 3840 | 230*120*800 | 13.5 | 380V/50HZ | 4800*1100*1100 |
QZB-10020F12 | 96PCS/20KGS | 7680 | 230*120*800 | 20.8 | 380V/50HZ | 5600*1100*1100 |
25kgs | QZB-5025F12 | 48PCS/25KGS | 2400 | 260*120*900 | 7.1 | 380V/50HZ | 3800*1100*1200 |
QZB-10025F12 | 96PCS/25KGS | 4800 | 260*120*900 | 13.5 | 380V/50HZ | 6400*1100*1200 |
QZB-10025S06 | 96PCS/25KGS | 9600 | 260*120*900 | 21.3 | 380V/50HZ | 5800*1100*1200 |
Zhejiang Kingfit Environment Co., Ltd.is subsidiary of Kingfit International Group Limited in East China, founded in 1998, with total capital of USD 5.38 million of Sino-joint venture enterprise. East China factory is located at Shuige Ind. Park in Lishui City of Zhejiang Province with convenient traffic, and covers a land area of 20000sqm. Our company is constantly introducing advanced manufacturing workmanship and testing equipment, invests 5% of it gross sales amount into R&D center every year and we established tight national testing center. The products are recognized by the users from abroad and at home and entitled "the Top 10 Well-known Refrigeration Equipment in China" and "National Quality Guaranteed and Eligible Product in Refrigeration Equipment Industry" etc. Our company introduced many leading technology production lines for the manufacture of screw style chiller, box-type chiller, cooling tower, freezing dryer, high temperature heat pump, ice making machine etc. The products are exported to more than 30 countries, this is a high tech enterprise integrated scientific research, production and trade, and is also currently the largest and most professional refrigerating and heating equipment manufacturer in China.
We have passed ISO9000, CE, AS certification, gradually becoming the navigator of industrial refrigerating and heating. And received many patented technologies, such as anti-corrosion flooded screw style chiller, flooded scroll style chiller, economizer, U-type anti-corrosion evaporator, external thread titanium evaporation, ice machine etc.
We sincerely welcome customers at abroad and home to our company for cooperation and let's make contribution to the flourish and development of refrigeration equipment in China together.
