19" Industrail Display with 5 Wire Touch Screen for Military, Navigation
| Price: |
US $ 38-348/Piece |
| Trade Terms: |
FOB |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Paypal,Money Gram,Western Union |
| Prod Model: |
GHK-19IP-TR |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Size: |
19 Inches |
| Resolution: |
1280X1024 |
| Brightness: |
250 Nits |
| Backlight: |
LED |
| Signal Input: |
VGA/VI |
| Backlight Lifetime: |
30000 Hours |
| Frame Stype: |
Steel Chassis |
| Type: |
TFT |
| Application: |
Surveillance |
| Aspect Ratio: |
4:3 |
| Feature: |
LED Backlight Display |
| Screen Size: |
19" |
| Interface Type: |
VGA |
Product Description
Product Specifications
LCD
Panel Type？AUO LCD Panel (Optional)
Resolution？1280*1024
Display Area(mm)？376.32(H)*301.06(V)
Brightness？450nits
Contrast Ratio？1000:1
Colors？16.2M/262k colors
View Angle？85/85/85/85
Backlight Lifetime？50000
ODS Control？Auto Menu Select(+,-)Exit On/Off
Touch Screen
Type？Infrared Touch Screen (Optional)
Resolution(pixel)？4096*4096
Touch Transmittance？>90%
Interface
Signal Input？VGA+DVI(15 Pin D-sub/DVI-D Connector) AV Input/Video Input/Video Input/Audio Input(Optional)
Touch Connectors？USB / RS232(Optional)
Power
Power Input？DC12V/4A (50~61HZ)-DC Jack (2.0mm)
Power Consumption？≤36W
Mechanical
Material？Steel chassis
Mounting？Support VESA Wall Mount and Embedded Mount
Dimensions？446.0(H)*339.0(V)*50.0(D)
Environment
Operating Temp？0~50 degree
Storage Temp？-20~60 degree
Relative Humidity？10~90% @40 degree？Non-condensing without touch screen
Vibration？1G peak,5~500Hz(Random)
Shock？15G peak acceleration (11msec.duration)
Rating？Meet EMI/EMC CE FCC Rohs
|
Panel size |
19" AUO panel |
|
Resolution |
1280x1024 |
|
Touch type |
5 wire resisitve USB/RS232 touch |
|
Backlights |
LED |
|
Certification |
CE/FCC/RoHS,CCC |
|
Front panel |
Aliuminum front panel |
Established in 2008, Ghaik is a high-tech enterprise integrating R&D, manufacturing, sale and service of industrial display products, Open Frame Touch Monitor, Chassis Monitor, Panel Mount Monitor, ATM Display, Kiosk Touch Display. We dedicated to providing high quality products and professional display solutions in the field of ATM, self-service kiosk, AFC, gaming etc...
Ghaik equipped modernized factory in Shenzhen, allow to produce 100, 000 units industrial touch LCD monitors annually. It is available for us to make delivery in a short lead time. Ghaik approved the ISO9001: 2008 quality management system certification, and all Ghaik products are qualified by the CCC, CE, FCC certifications.
Ghaik adhering "professional, integrity, efficiency" enterprise ideas to achieve win-win situation with all customers.
Management Philosophy
Development Concept: Development Innovation, Continuous Development, Pursuit of Excellence.
Technology Concept: Focusing on enterprise cost control, integrated manufacturing, product sales, research innovation, market insight, the increase in enterprise technical content, in order to meet customer needs for the purpose of technical innovation, enterprise and brand rise in value.
Talent Concept: Talent is the fundamental enterprise development. Ghaik Technologies always pay attention to talents, respect talents. "Only is to use" — — Have the best talents used in the most appropriate places. On an equal and harmonious atmosphere, we provide every employee with a good development platform and a selfpresentation stage.
Cooperation Concept: Both every employee and each department are important links of corporate connection. Only high-quality staffs trained a dedicated, united, pragmatic, integrity-based, professional team, forming a strong cohesive force, we can promote the enterprise virtuous circle.
Corporate Culture
Integrity: Sincerity-oriented, to the letter for the road; Honesty and trustworthiness are our enterprise characters, is a solemn promise Ghaik Technologies make to partners and customers.
Concentration: We are professional, because we are more dedicated. Ghaik Technologies advocate concentrative attention, spiritous concern, to put all the focus on one thing to do, so deep, so fine.
High-efficiency: Act decisively, purse high-efficiency. Ghaik Technologies regard swiftness and high-efficiency as corporate style, not only pursue the speed, but also pay attention to the ways of doing things, emphasizing the principle of an efficient, results-oriented.
Innovation: Starting from zero, keen innovation. Ghaik Technologies believes the only constant is change itself, innovation is the only way to extend the corporate life. Innovation make us secure as a mountain, calm ease, when facing complex, diverse, the volatile market structure.
