| Prod Model: |
LA110P |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Frequency Response: |
38Hz-100Hz(±3dB) 30Hz-120Hz(-10dB) |
| Power Rating: |
100W |
| Lf Driver: |
2×15"(75mm Voice Coil)Neodymium Woofer |
| Spl: |
127dB Spl,133 dB Spl Peak |
| Voltage Requirement: |
200-240V~ 50-60Hz |
| Amplifier Module: |
Three Channel Amplifier Module(Max4700W) |
| Signal Noise Ratio: |
102.5 dB(CH 1),103dB(CH 2,3) |
| Way Of Input: |
Power Supply,XLR Male & Female |
| Input Impedance: |
20kohm Balanced/10kohm Unbalanced |
| Output Connection (Full Range): |
Nl4MP Neutrik Connector(1+/1-:Lf / 2+/2-:Hf) |
| Noise: |
<102dB |
| Hi-Fi: |
Not Hi-Fi |
| Operation Mode: |
Touch Control |
| Speaker System: |
Mono |
| Speaker Material: |
Wood |
| Certification: |
SGS |
| THD: |
>0.01% |
| Application: |
Touring Performance, Theatre ,Church etc |
| Monitor: |
None |
Product Description
15inch pa neodymium bass audio speaker LA110P is a reflex subwoofer selfpower speaker. It consists of 2×15'' LF drivers and three channels amplifier module. ( Maximum power is 4700W).It is suitable for varies of applications, such as all kinds of touring sound and music reinforcement performances, as well as large numbers of fixed installations. It can be used in conjunction with other full range loudspeakers to outstanding excursion in LF. And it suggested that LA110P used better with LA110 single 10" line array speaker.
Feature:
Dual 15" rubber edge neodymium speaker selfpower subwoofer
Built-in 700W+2*2000W powered amplifier module
Driver 1-4pcs LA110 line array speaker
Its size&appearance is exactly the same rigging, can stack and hanging
Applications:
Touring performance
Theatre and multi-function hall
Church
| TECHNICAL SPECIFICATION |
| Frequency range(include powered module) | 38 Hz ~ 100Hz (+3 dB ) 30 Hz ~ 120Hz (-10dB ) |
| Normal power (AES) | 1000W |
| LF driver | 2×15"(75mm voice coil)neodymium woofer |
| SPL | 127dB SPL,133 dB SPL peak |
| Voltage requirement | 200-240V~ 50-60Hz |
| Amplifier module | Three channel amplifier module(MAX4700W) |
| Total harmonic distortion (1KHz, full frequency 4Ω) | ≤1% |
| Signal noise ratio | 102.5 dB(CH 1),103dB(CH 2,3) |
| Active gain (1KHz 8Ω) | 20 dB (CH 1),32 dB (CH 2,3) |
| Way of Input | Power supply,XLR male & female |
| Input impedance | 20KΩbalanced/10KΩunbalanced |
| Output connection (full range) | NL4MP NEUTRIK connector(1+/1-:LF / 2+/2-:HF) |
| Output circuit style | D class |
| Cooling system | Forced cooling fan |
| PHYSICAL DATA |
| Dimension(H×W×D) | 680×580×796(mm) |
| Weight (include powered module) | 60(kg) |
| Connection plug | XLR+POWERCON+SPEAKON |
| Rigging hardware | Hanging pendant + top support |
| Material of enclosure | 15mm,18mm,24mm multiply-plywood |
| Surface | Black water paint |
| Grille | Black porous steel net + water splash sound transparent cloth |
Our advantages:1) Global leading professional Manufacturer of professional speaker and amplifier.2) Product quality: Superior speaker and amplifier, top technology and quality.3) Certificate: CE,RoHS,GS,SGS,ISO90014) Monthly Production Capacity: 2000pcs5) Fast delivery: Get your order when you need it.6) 4000 square meters workshop, with about 200 workers and 20 professional engineers7) Convenient Transportation: 1 hour to Baiyun Airport8) 24 hours on line service.
Guangzhou Zsound Proaudio Technology Co., Ltd. Specilizes in developing and manufacturing a wide range of superior, advanced technology loudspeakers for the professional touring and installation market. With more than ten-years R & D experience, we've successively achieved numerous patents for Zsound speakers.
Designed and constructed to exacting specifications, every component of Zsound loudspeaker is critically extracted. This meticulous craftsmanship and attention to detail shows how seriously we believe in our ideas. Our pursuit for sonic excellence LED to an outstanding reputation in this industry.
During the long-term persistent efforts, Zsound loudspeakers are extensively used in rental and installation markets for events, multimedia, musicals, concert halls, theatres, broadcast and many other applications from the smallest conference room to the largest stadium.
What's most important, ZSOUND won the specified audio title of the Milan World Expo (China Pavilion) theatrical performances, and provides sound equipment and technical support service for China Pavilion theatrical performance
In March 2013, ZSOUND set up performance alliance, the purpose is "achieve resource sharing under the premise of the law of the market, promote the growth of alliance members". And now there're more than 17 members from ZSOUND performance alliance, users of line array system are up to 1000 throughout the country.
After two-years development, alliance members have successfully made a cooperation with some performance project, such as Kenny'G Tour, Lang Lang Concert, Zero Band Tour and Inner Mongolia Sport etc.
Meanwhile, ZSOUND's desire is to provide the best professional audio system and technology service for user, as well as audio company which becomes worthy of audio industry's respect, the goal is to be the leading international professional audio brand.
