| Prod Model: |
ZSOUND MA1300Q |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Lead Time: |
7-10 Days |
| Type: |
Professional Amplifier |
| Size: |
483*377*88mm |
| Frequency Response: |
20Hz-25kHz+/-0.5dB |
| Signal Noise Ratio (dB): |
110dB |
| Input Connectors (Per.CH): |
3-Pinxlr, Electronically Balanced |
| Power Requirement: |
200-240V~(50Hz-60Hz) |
| Output Connectors: |
Speakon Connectors (Neutrik) |
| Net Weight: |
13kg |
| Service: |
CE, RoHS, GS |
| Used For: |
Professional |
| Output Number: |
4 |
| Voltage: |
AC 220V |
| Function: |
Post Amplifier |
| Tube Type: |
Transistor Amplifier |
| Element Number: |
Push-Pull Amplifier |
| Conductive Mode: |
D |
| Usage: |
Sound Reinforcement |
| Sound Channel: |
Stereo |
Product Description
1300W music power amplifier:
1. 4CH x1300W @ 8 ohms Switching Power Amplifier
2. MA1300Q Switching Mode Amplifier
3. 13kg Net Weight Switching Mode Amplifier
Proaudio, Loudspeaker, speaker, line array speaker, PA speaker, outdoor speaker, subwoofer, small speaker, active speaker, self-power speaker, powered speaker, amplifier, professional amplfier, Disco speaker, chuch speaker, switching power amplifier, transformer amplifier, mainly designed for live
Performance, stadium, outdoor use, fixed installation.
ZSOUND PRO audio Switching Power Amplifier (4CH MA1300Q )
Model No.: ZSOUND MA1300Q
8 ohms stereo power: 4x1300W
4 ohms stereo power: 4x2200W.
|
4ch Professional Amplifier |
MA 1300Q |
|
Output power |
|
8Ω Stereo power |
4× 1300W |
|
4Ω Stereo power |
4× 2200W |
|
2Ω Stereo power |
4× 2400W |
|
8Ω Bridged Mono power |
2× 4400W |
|
4Ω Bridged Mono power |
2× 4800W |
|
|
|
Technical specification |
|
Frequency Response |
20Hz~25kHz± 0.5dB |
|
THD+N(Rated power, 4Ω /KHz)% |
0.1% |
|
Signal Noise Ratio(dB) |
110dB |
|
Optional magnifaction |
23, 26, 29, 32, 35, 38, 41, 44dB |
|
Input connectors(per. ch) |
3-pin XLR, electronically balanced |
|
Input imdepance |
20kΩ Balanced/10kΩ Unbalanced |
|
Output connectors |
Speakon Connectors (Neutrik) |
|
Power |
|
Power Requirement |
200v~240v(50Hz~60Hz) |
|
Minimun voltage |
180-260V~50-60Hz |
|
|
|
Dimension |
483× 377× 88mm |
|
Weight |
13Kg |
Guangzhou Zsound Proaudio Technology Co., Ltd. Specilizes in developing and manufacturing a wide range of superior, advanced technology loudspeakers for the professional touring and installation market. With more than ten-years R & D experience, we've successively achieved numerous patents for Zsound speakers.
Designed and constructed to exacting specifications, every component of Zsound loudspeaker is critically extracted. This meticulous craftsmanship and attention to detail shows how seriously we believe in our ideas. Our pursuit for sonic excellence LED to an outstanding reputation in this industry.
During the long-term persistent efforts, Zsound loudspeakers are extensively used in rental and installation markets for events, multimedia, musicals, concert halls, theatres, broadcast and many other applications from the smallest conference room to the largest stadium.
What's most important, ZSOUND won the specified audio title of the Milan World Expo (China Pavilion) theatrical performances, and provides sound equipment and technical support service for China Pavilion theatrical performance
In March 2013, ZSOUND set up performance alliance, the purpose is "achieve resource sharing under the premise of the law of the market, promote the growth of alliance members". And now there're more than 17 members from ZSOUND performance alliance, users of line array system are up to 1000 throughout the country.
After two-years development, alliance members have successfully made a cooperation with some performance project, such as Kenny'G Tour, Lang Lang Concert, Zero Band Tour and Inner Mongolia Sport etc.
Meanwhile, ZSOUND's desire is to provide the best professional audio system and technology service for user, as well as audio company which becomes worthy of audio industry's respect, the goal is to be the leading international professional audio brand.
