| Prod Model: |
PIA120 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Power Supply Voltage: |
110~125V AC or 220 |
| Rated Power: |
120W |
| Frequency Response: |
50~15,000Hz(±3db) |
| Working Temperature: |
-10to +40 |
| Size(W*H*D): |
483X90X410mm |
| Weight: |
11kg |
| Color: |
White |
| Type: |
Professional Amplifier |
| Function: |
Amplifier Combined |
| Element Number: |
Monoamplifier |
| Used For: |
Professional |
| Tube Type: |
Transistor Amplifier |
| Usage: |
Commercial |
Product Description
Product description
PIA120series is the high performance audio amplifier which are designed for commercial and industrial public address applications. This type is the standard mount design, rated power is 120W to provide a wide selection for different sound system. Both balanced and unbalanced line inputs are selectable, 100V,70V and 4ohm are selectable for different speaker installation matching. Complete protection includes short circuit, overload and overheat automatic protection.
Features
1. standard mount design, humanistic design, exquisite technique, show the top grade quality
2. MIC1-2 microphone balanced input,
3. AUX1-2 line RCA linear input,AUX3 line RCA linear or RJ45 input
4. 1V600Ωpre-out
5. constant pressure output 100V/70V and rated resistance 4Ω;
6. Signal lamp, peak lamp display
7. On/off impact protection speaker
Application and management
Applied in airport, station, coffee shop, market, square, school, park, district and other places.
Port allocation:
1. MIC 1~6 line microphone balanced input, input sensibility: 3~10mV;
2. Aux 1~2 line RCA linear input, input sensibility: 100mV or 300mV switchable;
3. Aux 3 line RCA linear input or RJ45 input, input sensibility: 100mV or 300mV switchable;
4. 4Ω,70V,100V output terminal multi-impedance output
5. Pre-out 1V 600Ω;
Specification
Model
PIA120
Power Requirement
110~125V AC or 220~230V AC,50/60Hz
Rate Output
120W
Distortion
Less than 0.8% at 1 kHz
Frequency Response:
50~15,000Hz(±3dB)
Output
Pre Output
0dB, 600ohm Unbalanced, RCA pin jack
Direct Output
High Impedance: 100V\70V screw terminal
Input
MIC1-2:
3 ~ 10mV balanced Phenix Input
AUX1-2:
300mV/100mV (-10dBV/-20dBV) Selectable Unbalanced,RCA pin jack
AUX 3/NETWORK INPUT:
300mV/100mV(-10dBV/-20dBV)Selectable Unbalanced,RCA pin jack,RJ45
Working temperature:
-10to +40
Size(W*H*D) :
483X90X410MM
Color:
Black
Weight:
11kg
