| Markets: |
Southeast Asia,Africa,Mid East,Eastern Asia |
| Cooling Method: |
Air Cooling /Water Cooling |
| Power Mode: |
3pH 380V/50Hz 415V/60Hz |
| Evaporating Temperature: |
-20 |
| Refrigerant: |
R404A/R22 |
| Inlet Water Temperature: |
16 |
| Ambient Temperature: |
35 |
| Ice Flake Thickness: |
1.8-2.5mm |
| Ice Flake Material: |
Stainless and Antisepsis Aluminum Alloy |
| Service Life: |
Above 20 Years |
| Applying: |
Supermarket, Meat Process etc |
Product Description
Flake ice application:
Flake ice has a variety of applications, for example, inside of packing box for fresh vegetable, which is in favor of long-distance transportation. Especially for tender fish stocks and transportation, such as trout, squid, cuttlefish and so on, the flake ice is the first choice, it is also applied for dry chemistry industry, large concrete project, large crude and fresh supermarket, , eat process, large fishery whole sale market, food processing company, and so on k.
Flake ice Feature:
1. The thin ice can be directly used foro stirring and mixing refrigerated materials
2. No acute edges and corners so it will not damage the surface of the cooled object.
3. Large contact area and fast cooling speed, by cooling to ensure that every part of the evenness of temperature
4. Easy to crush and mold.
Flake ice machine Feature:
1. Automatic control: The whole system is automatically controlled and easy to use, operation starts by merrely switching on one button, and terminates, automatically when ice is full.
2. Safe and reliable: All parts are provided by international cooperating suppliers and every part is strictly tested before using, a low-hitch protection system is also installed to protect the machineby using the highest imported quality components and non-corrosive material, the flake ice sealed in the freshness safely to prolong the quality of the produce.
3. Perfect flexibility: It can be used in an ambient temperature ranging from 5 to 35, specially designed types are able to function normally under the worst conditions.
Installation:
Ice lolly machine has been installed and tested before delivery, only needs customers to connect the wate rpipe and power.
Packing way:
Packed in air bubble film inside, then in wooden box outside.
|
model |
daily output
kg/24h |
ref. capacity
kcal/h |
evaporating temp
|
total power
kw |
power
supply |
cooling
method |
|
QFI-0.35F |
350 |
1645 |
-20º C |
2.5 |
3P 380V/50HZ |
air cooling |
|
QFI-0.5F |
500 |
2350 |
-20º C |
2.7 |
3P 380V/50HZ |
air cooling |
|
QFI-0.8F |
800 |
3760 |
-20º C |
3.5 |
3P 380V/50HZ |
air cooling |
|
QFI-1F |
1000 |
4700 |
-20º C |
4.5 |
3P 380V/50HZ |
air cooling |
|
QFI-1.2F |
1200 |
5640 |
-20º C |
5.0 |
3P 380V/50HZ |
air cooling |
|
QFI-1.5F |
1500 |
7050 |
-20º C |
8.3 |
3P 380V/50HZ |
air cooling |
|
QFI-2F |
2000 |
9400 |
-20º C |
9.7 |
3P 380V/50HZ |
air cooling |
|
QFI-2.5F |
2500 |
11750 |
-20º C |
10.2 |
3P 380V/50HZ |
air cooling |
|
QFI-3F |
3000 |
14100 |
-20º C |
11.2 |
3P 380V/50HZ |
air cooling |
|
QFI-4S |
4000 |
18800 |
-20º C |
15.1 |
3P 380V/50HZ |
water cooling |
|
QFI-5S |
5000 |
23500 |
-20º C |
18.0 |
3P 380V/50HZ |
water cooling |
|
QFI-8S |
8000 |
37600 |
-20º C |
30.5 |
3P 380V/50HZ |
water cooling |
|
QFI-10S |
10000 |
47000 |
-20º C |
31.0 |
3P 380V/50HZ |
water cooling |
|
QFI-12S |
12000 |
56400 |
-20º C |
42.1 |
3P 380V/50HZ |
water cooling |
|
QFI-15S |
15000 |
70500 |
-20º C |
56.0 |
3P 380V/50HZ |
water cooling |
|
QFI-20S |
20000 |
93500 |
-20º C |
63.0 |
3P 380V/50HZ |
water cooling |
|
QFI-25S |
25000 |
116875 |
-20º C |
78.3 |
3P 380V/50HZ |
water cooling |
|
QFI-30S |
30000 |
141000 |
-20º C |
102.5 |
3P 380V/50HZ |
watercooling |
|
QFI-40S |
40000 |
188000 |
-20º C |
124.3 |
3P 380V/50HZ |
water cooling |
|
QFI-50S |
50000 |
235000 |
-20º C |
147.4 |
3P 380V/50HZ |
water cooling |
Zhejiang Kingfit Environment Co., Ltd.is subsidiary of Kingfit International Group Limited in East China, founded in 1998, with total capital of USD 5.38 million of Sino-joint venture enterprise. East China factory is located at Shuige Ind. Park in Lishui City of Zhejiang Province with convenient traffic, and covers a land area of 20000sqm. Our company is constantly introducing advanced manufacturing workmanship and testing equipment, invests 5% of it gross sales amount into R&D center every year and we established tight national testing center. The products are recognized by the users from abroad and at home and entitled "the Top 10 Well-known Refrigeration Equipment in China" and "National Quality Guaranteed and Eligible Product in Refrigeration Equipment Industry" etc. Our company introduced many leading technology production lines for the manufacture of screw style chiller, box-type chiller, cooling tower, freezing dryer, high temperature heat pump, ice making machine etc. The products are exported to more than 30 countries, this is a high tech enterprise integrated scientific research, production and trade, and is also currently the largest and most professional refrigerating and heating equipment manufacturer in China.
We have passed ISO9000, CE, AS certification, gradually becoming the navigator of industrial refrigerating and heating. And received many patented technologies, such as anti-corrosion flooded screw style chiller, flooded scroll style chiller, economizer, U-type anti-corrosion evaporator, external thread titanium evaporation, ice machine etc.
We sincerely welcome customers at abroad and home to our company for cooperation and let's make contribution to the flourish and development of refrigeration equipment in China together.
