Fp10000q 4 Channel Switching Power Amplifier

Fp10000q 4 Channel Switching Power Amplifier
Price: Negotiable/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 2/Piece
Pay Type: L/C,T/T,Paypal,Money Gram,Western Union
Prod Model: FP10000Q
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Model Number: Fp10000q
System Type: 4 Channels Switch Power Supply
Frequency Response (±3 Db): 20 Hz - 20 kHz
Power Rating: 1300W X4 at 8 Ohms
Channel: 4 Channels
Max Output Power(8ohm): 1300W X 4
Net Weight: 14kg
Color: Black
Type: Professional Amplifier
Used For: Professional
Tube Type: Transistor Amplifier
Output Number: 4
Usage: Professional Performance
Function: Switch Power Supply Amplifier
Voltage: 220V or 110V

Product Description

Product Description

 FP10000Q  Line Array Power Amplifier

4*1300W power amplifier
High power amplifiers
Amp amplifier with light weight
Switching power supply amp


FP10000Q 4ch big power amplifier is the latest design of Skytone audio, switching power supply amps. FP series including two models: FP10000Q amplifier, FP6000Q amp.
New designed with the stable performance and high quality. Gorgeous appearance and full of modern taste, and walking at the forefront of famous brand of entertainment sound equipment.



FP10000Q Features:

1. The lastest design power amplifiers
2. Gorgeous appearance
3. Switch power supply amp amplifiers
4. Light weight amp
5. Big power amps

Professional amp amplifiers give you the best sound;
Professional manufacturer gives you the best price.



4  channel  switch  power  supply  amplifier
Specifications
ModelFP6000QFP10000Q
Max Output  Power(8ohm)800W× 41300W× 4
Max. Output  power(4ohm)1300W× 42080W× 4
Max. Output  power(4ohm)1500W× 42500W × 4
T. H. D(1W. 20Hz-20KHz)< 0.1 %
Signal  To  Noise  Ratio112dBA
Cross  Talk(1KHz)70dB
Frequency  Response10Hz-35KHz
Default  Gain35dB
Gain  Selectable23, 26, 29, 32, 35, 38, 42, 44dB
lnput  Connecters3-Pin  XLR.
Onput  ConnectersNeutrik  Speakon
Main  Power  Supply~ 220V(± 10 % )50-60Hz
Weight13Kg14Kg
Dimensions483(W)× 396(D)× 88(H)mm

Compare FP10000Q of Skytone and other factories:

1. General outlook:




2. Skytone: 3mm thick aluminum radiator;have PCB board
Other factories: 1mm common thin iron plate;no PCB board


3. Skytone: fixing with manganese;
Other factories: no manganese;
Note: Manganese plate is fixing on the high voltage  output transistor for better connection and heat dissipation.


4. Skytone: pure copper cable plating  with silver: Withstand high  temperature & brighten high  frequency.

Other factories: very common wire

5. Transistor compare:
Skytone: exquisite original Sanken transistor

Use a sharp tool to scratch heatsink, you will know: Skytone's is pure copper; while other's is aluminum coated copper.

Other factory: ugly old transistor, looks like copy or second hand

6. Copper Heatsink compare:
Skytone Heatsink:
1)Pure copper; 2)15mm thick; 3)45mm wide
Other factories: 1) aluminum coted copper 2) 12mm thick 3) only 29cm wide



Guangzhou Skytone Audio Co., Limited, was founded in 2004. Our office is located in the beautiful, bustling Guangzhou City, in Yilong Industrial Zone, Baiyun District, near Baiyun Lake.

We are specialized in professional loudspeakers, karaoke speakers, amplifiers and other audio peripheral such as microphone, mixer, equalizer, compressor, ect.

Our company gains a good reputation with good management mechanism, advanced technology, strong force of R&D, excellent quality and perfect after-sales services. There are many departments in our company including R&D, engineering, production, marketing, after-sales services and personnel.

To meet market developments and customers' needs, our company will continue to improve the product structure, operational management, as well as comprehensive quality of the staff. With brand-new products, vigorous power and stable paces, we will work hand-in-hand with customers home and abroad to create brilliant future!
